GLS ZD400

GLS ZD400

The GLS ZD400 chamfering line is designed for high-precision chamfering, cutting, and grinding of kerbstones. Engineered for professional stone processing lines, it combines automation, accuracy, and stability to deliver consistent finishing quality for sidewalk and kerbstone production.

Key Features
• High-Precision Chamfering: Automated chamfering and grinding system ensures consistent edge quality and accurate processing results.
• Intelligent Control System: Equipped with smart control features allowing real-time monitoring and optimized production management.
• Industrial Stability & Durability: Premium components and heavy-duty construction guarantee stable operation and long-term reliability.

Superior Stability:
Reinforced structure providing high
stability during operation.

High Precision:
Suitable for precise and complex
engravings with high detail fidelity.

Easy Maintenance:
Simplified maintenance system
for increased durability.

Prix

On request

We ship worldwide

Technical datas

Specification GLS-ZD400 Unit
Blade diameter Ø350 – Ø400 mm
Grinding wheel diameter Ø150 / Ø180–Ø200 / Ø250 mm
Number of heads 10
Maximum cutting size (L×W×H) 1200 × 300 × 300 mm
Maximum chamfering size 10–50 (customizable) mm
Maximum grinding speed 15 m/min
Minimum motor power 55 kW
Weight 7 tons
Overall dimensions (L×W×H) 7200 × 7800 × 2300 mm

France - USA - China - Brazil

Request a quote
